Function, Structure |
single speed |
|
Suitable Engine |
150 and below |
|
Max Load Capacity (contain vehicle weight) |
1000Kg |
|
Hub Connection Hole Distance A |
4-hole center distance φ100、φ102、φ114; 5-hole center distance φ140 |
|
Input Connection Specifications |
rectangle spline (6×20×17×4) or flange（center distance φ73.54、4×M8） |
|
Hub Connection Hole Diameter B |
4-hole M12×1.25、4-hole M14×1.5 |
|
Main Reduction Ratio |
13:37、15:37、12:38、9:35 |
|
Brake Diameter |
φ160、φ180 |
