Motor Connector |
square flange：152×152 |
|
Input Connect |
internal spline connect specifications：m=1, z=22,α=20 |
|
Suitable Motor |
Input Max Torque≤110N.m |
|
Total Reduction Ratio |
1∶6.352 （can adjust between 5-12） |
|
Differential Mechanism Speed Ratio |
10:16 |
|
Center Distance Between Input & Output |
166 |
|
Body Place, Install Ways |
FT horizontal (RR horizontal, connect with frame through hang-up hole) |
