Motor Connector |
square flange 140×40 |
|
Input Connect |
spline connect specifications：m=1, z=18,α=20 |
|
Suitable Motor |
input torque≤50N·m |
|
Speed Ratio |
1∶12.76 1∶10.09 1∶8.15 |
|
Plate Wheel Connection Size |
4-hole bolts：M12×1.25，center distance φ114.3 |
|
Wheel Distance |
1080 (according to users’ demands) |
|
Brake Mode |
hydraulic disc brake, brake diameterΦ180 (according to users’ needs) |
|
Body Place, Install Ways |
FT horizontal (vertical upwards & RR horizontal) |
